Details

Product Specification :

Carbon Brush: 203

Continuous rating input : 2,100W

Collet Capacity : 12 mm (1/2″) ; 12 mm or 13.7lbs.

Collet Size: 6, 8, 10, 12 mm (1/4, 3/8, 1/2″)

Plunge Capacity : 0 – 70 mm (0 – 2-3/4″)

Base dia.: 170 mm (6-11/16″)

Base Inner : 62 mm (2-7/16″)

No Load Speed (RPM) : 9,000 – 23,000

Vibration Level : Cutting Grooves in MDF: 4.2 m/s²

Vibration K Factor : Cutting Grooves in MDF: 1.5 m/s²

Sound Pressure Level : 88 dB(A)

Sound Power Level : 99 dB(A)

Noise K Factor : 3 dB(A)

Dimensions (L x W x H) : 155 x 294 x 327 mm (6-1/8 x 11-5/8 x 12-7/8″)

Net weight : 6.2 kg (13.7 lbs.)

Power supply cord : 4.0 m (13.1 ft.)

Anti-restart function engineered to minimize motor start up when battery is inserted with switch locked on
Combines power and precision for the most demanding routing applications
Powerful 2,100 W motor delivers 9,000-23,000 RPM for the most demanding applications
Constant speed control maintains constant speed under load
Variable speed control dial enables user to match the speed to the application
Soft start feature for smooth start-ups
Electric brake for maximum productivity and increased operator safety
Deep 0 – 70 mm (0″ – 2-3/4″) plunge depth capacity for easy penetration into work piece
Linear ball bearings for smooth plunge action and superior performance
Quick release plunge depth adjustment with micro control along with 3 preset depth stops for added precision
Dual LED lights with afterglow feature illuminate the work area
Oversized ball bearing construction for longer tool life
Ergonomic rubberized handles with built-in large two-finger switch for added control and use
Conveniently located plunge lock lever for efficient operation
Shaft lock for quick and easy bit changes
Tool-less templet guide system for quick and easy installation and removal
Trigger switch with a lock button for lock-off and lock-on functions
